Brand:
SunEvoPower Range:
560-580WMax. Efficiency:
22.4%Number of Cells:
110 Cells (5x22)Dimensions of Module L*W*H:
2384 x 1096 x 35mmWeight:
32.3kgFront Side Glass:
High transparency solar glass 2.0mmBack Side Glass:
High transparency solar glass 2.0mmFrame:
Black/Silver, anodized aluminium alloyJunction Box:
IP68 Rated, 3 DiodesCable:
4.0mm2, 200mm(length can be customized)Wind/Snow Load:
2400Pa/5400PaConnector:
MC4 CompatibleBifaciality:
80±5%
EVO 6 Pro 110 Half Cells 580W 575W 570W 565W 560W Bifacial Dual Glass Solar Module
In order to create the ultimate cost-effective product, SunEvo Solar launched a new generation of ultra-high efficiency HJT solar modules, the Evo 6 Pro monocrystalline N-type HJT bifacial double glass 680-700Watt photovoltaic solar panel. The new series integrates 210mm silicon wafers, with HJT, bifacial, multi-busbar cell technology and high-density encapsulation. The maximum power output on the front side of the three formats, 110 / 120 / 132 half cells, maximum output power reach 700Wp. Meanwhile, based on different installation environments, the rear side power generation gain is between 10-30%.
Electrical Specification
|
Maximum Power (Pmax/W) |
560 |
565 |
570 |
575 |
580 |
|
Maximum Power Voltage (Vmp/V) |
34.17 |
34.35 |
34.53 |
34.71 |
34.88 |
|
Maximum Power Current (Imp/A) |
16.39 |
16.45 |
16.51 |
16.57 |
16.63 |
|
Open Circuit Voltage (Voc/V) |
40.77 |
40.96 |
41.16 |
41.35 |
41.54 |
|
Short Circuit Current (Isc/A) |
17.19 |
17.25 |
17.31 |
17.37 |
17.43 |
|
Module Efficiency (%) |
21.4 |
21.6 |
21.8 |
22.0 |
22.2 |
|
Power Output Tolerance (W) |
0~+5W |
||||
|
Temperature Coefficient of Isc |
+0.04%/°C |
||||
|
Temperature Coefficient of Voc |
-0.24%/°C |
||||
|
Temperature Coefficient of Pmax |
-0.26%/°C |
||||
Certifications
All of SunEvo's products have been certified by professional third-party testing bodies around the world, and the testing conditions are complex and diverse, from ordinary installation conditions to various extreme weather conditions, natural environments. We pursue the ultimate in quality and provide the best guarantee for customers' assets and profits.
What's the advantage of HJT bifacial dual glass solar panels?
Evo 6 Pro Series 120 Half Cells Solar PV Panel 615W 620W 625W 630 Wp 635 Watt Monocrystalline N Type HJT Bifacial Double Glass Multi Busbar Photovoltaic Solar Panel Module Based on 210mm Solar Cells
Evo 6 Pro Series 132 Half Cells Solar PV Panel 680W 685W 690W 695Wp 700Watt High Effficiency Monocrystalline HJT Bifacial Double Glass Photovoltaic Solar Panel Module Based on 210mm Solar Cell
The 710W HJT module combines cutting-edge technology, superior product features, and high-efficiency performance to redefine the standards of solar power generation. Combining the gettering process and single-side μc-Si technology to ensure higher cell efficiency and higher module power.
The 645W HJT module combines cutting-edge technology, superior product features, and high-efficiency performance to redefine the standards of solar power generation. Combining the gettering process and single-side μc-Si technology to ensure higher cell efficiency and higher module power.
Unlock the full potential of solar energy with Jinko solar cutting-edge N-type 580W panels. From customizable orders starting at just 1 pallet of 31 panels to the bifacial design for increased power output, our Jinko solar panels ensure maximum efficiency, allowing you to generate more electricity per unit area. Elevate your solar experience with our high-performance, versatile solution.
Our 210mm N-Type Topcon Solar Panels offer unmatched performance with features like reduced LID and enhanced PID resistance, ensuring durability and stability for high-efficiency modules. With minimized sealing damage and CTM loss rates, they're designed to optimize energy output. Plus, boasting a low power temperature coefficient of -0.30%/°C, they excel even in low irradiance environments, achieving a remarkable relative conversion efficiency of up to 98% under low light conditions (200W/m²). With impressive front efficiency of 25% and a bifaciality rate exceeding 80%, our panels deliver exceptional conversion efficiency for maximum energy generation.
Trina Solar, the global PV and smart energy total solutions provider, has unveiled its latest head-turner, the Vertex N 610W for C&I and utility-scale projects. Together with the Vertex N 700W for utility scenarios and Vertex S+ 450W for rooftop PV systems, Trina Solar’s n-type module portfolio is based on the leading 210 product technology platform and n-type i-TOPCon cell technology. The release of Vertex N will hit and reshape the PV market again.
Installing a solar-powered air conditioner can be a great to reduce your energy consumption and lower your carbon footprint.
